M3600
Fullas
Multiple Charging and Output Ports, Meets Your Charging Needs in any Situation, Ensuring Convenient and Fast Charging Wherever you are.
With Ability to Connect External Battery Packs, Use It As Home Backup Power to Stay Powered Up during Blackout.
Parameter
| GENERAL | Model | M1200 | M2200 | M3600 | P3600 | M5000 | P5000 |
| Capacity | 1209Wh | 2240Wh | 3586Wh | 3584Wh | 5120Wh | 5120Wh | |
| Cell Chemistry | LiFePO4 | LiFePO4 | LiFePO4 | LiFePO4 | LiFePO4 | LiFePO4 | |
| Lifecycle | 4000+Cycles to 80% capacity | 6000+Cycles to 80% capacity | |||||
| lndicator | APP/TFT Screen | APP/TFT Screen | APP/TFT Screen/Web | / | APP/LCD Screen/Web | / | |
| Storage Temp. | (-4ºF~-140ºF(-20ºC~60ºC) | ||||||
| Operating Temp. | (32ºF~122ºF(0ºC~50ºC) | ||||||
| Material | ABS + PC | ABS + PC | Metal/ABS + PC | Metal/ABS + PC | Metal | Metal | |
| Weight | 13±0.5kg | 22±0.5kg | 36±0.5kg | 35±0.5kg | 90±0.5kg | 46±0.5kg | |
| Dimensions | 400*195*200mm | 400*260*270mm | 600*320*700mm | 600*320*700mm | 721*408*809mm | 579*476*210mm | |
| BMS | OVP,UVP,OCP,SCP,OTP,UTP,etc. | ||||||
| Solar System | MPPT Charge Controller/ | ||||||
| INPUT | AC#1 | 1200W Max | 2000W Max | 3600W | / | 2000W Max | / |
| AC#2(Grid) | / | / | / | / | 5000W Max | / | |
| XT60 | 500W Max | 500W*2 Max | / | / | / | / | |
| XT90 | / | / | 1600W*2 | / | / | / | |
| MC4 solar | / | / | / | / | 7000W Max | / | |
| OUTPUT | AC#1 | 1200W Max | 2400W Max | 3600W Max | / | 2000W Max | / |
| AC#2(Grid) | / | 5000W Max | / | ||||
| AC#3(EPS) | / | / | / | / | 5000W Max | / | |
| / | / | / | / | Auto Switchover Time<20ms | / | ||
| USB-A | 18W Max | 18w Max(5V-12V) | 18W Max | / | / | / | |
| USB-C#1 | 100W Max | 45W Max | 45W Max | / | / | / | |
| USB-C#2 | / | 100W Max | 100W Max | / | / | / | |
| DC5525 | 120W(12V/10A) | 120W(12V/10A) | 120W(12V/10A) | / | / | / | |
| Car Charger | 120W(12V/10A) | 120W(12V/10A) | 120W(12V/10A) | / | / | / | |
Equipment & workshop
Q1:Can you supply OEM &ODM service ?
A:Yes, but there is a minimum order quantity required.
A:We have long-term cooperated forwarders who are professional at battery shipment.
Service:
We will reply you in 24hours, Sincerely welcome to contact us for more details.
